量程范围Range range
|
-100~1Kpa~100 MPa
|
量程可选The range is optional
|
|
压力类型 Pressure type
|
表压、绝压Gauge pressure 、 absolute pressure
|
默认表压 default Gauge pressure
|
|
输出信号Output signal
|
4-20 mA,0-5V ,0-10V
|
默认default 4-20 mA
|
|
供电电源 Power supply
|
12~24 VDC
|
|
|
精度等级 Accuracy level
|
0.5%FS ,0.2%FS 0.1%FS
|
默认default 0.5% FS
|
|
补偿温度Compensating temperature
|
-10~70 ℃
|
|
|
工作温度 Working temperature
|
-20~80 ℃
|
|
|
零点温度漂移Zero temperature drift
|
0.5% FS（MAX）
|
|
|
灵敏度温度漂移Sensitivity temperature drift
|
0.5% FS（MAX）
|
|
|
压力过载Pressure overload
|
10MPa以下2倍；25MPa以上1.5倍
|
Less than 2 times 10MPa; 25MPa or more than 1.5 times
|
|
机械振动Mechanical vibration
|
20G（20-5000Hz）
|
|
|
响应时间Response time
|
每秒20次
|
20 times per second
|
|
稳定性stability
|
≤0.2%FS/年（year）
|
|
|
绝缘度insulation
|
≤500㏁
|
|
|
防护等级Class of protection
|
IP65
|
|
|
外壳材料Housing material
|
外壳低铜铝合金；304不锈钢接头
|
Low copper aluminum alloy shell; 304 stainless steel joint
|
|
介质兼容Media compatible
|
与316L兼容的流质介质
|
Liquid media compatible with SS 316L
|
|
量 程 范 围 表LM Range Table
|
|
代号CN
|
量程LM
|
代号CN
|
量程LM
|
代号CN
|
量程LM
|
代号CN
|
量程LM
|
|
W1
|
0~1kPa
|
W9
|
0~25 kPa
|
W17
|
0~1.0 MPa
|
W25
|
0~40 MPa
|
|
W2
|
0~2kPa
|
W10
|
0~40 kPa
|
W18
|
0~1.6 MPa
|
W26
|
0~60 MPa
|
|
W3
|
0~3 kPa
|
W11
|
0~60 kPa
|
W19
|
0~2.5 MPa
|
W27
|
0~100 MPa
|
|
W4
|
0~4 kPa
|
W12
|
0~100 kPa
|
W20
|
0~4 MPa
|
W28
|
-100 kPa ~0
|
|
W5
|
0~6 kPa
|
W13
|
0~0.16MPa
|
W21
|
0~6 MPa
|
W29
|
-100 ~100 kPa
|
|
W6
|
0~10 kPa
|
W14
|
0~0.25 MPa
|
W22
|
0~10 MPa
|
W30
|
-100~300 kPa
|
|
W7
|
0~16 kPa
|
W15
|
0~0.4 MPa
|
W23
|
0~16 MPa
|
其它订货型号请备注Other order type please comment
|
|
W8
|
0~20 kPa
|
W16
|
0~0.6 MPa
|
W24
|
0~25 MPa
|
|
|
|
