量程范围Range range
|
-100~1Kpa~100 MPa
|
量程可选The range is optional
|
|
压力类型 Pressure type
|
表压、绝压Gauge pressure 、 absolute pressure
|
默认表压 default Gauge pressure
|
|
输出信号Output signal
|
4-20 mA,0-5V ,0-10V
|
默认default 4-20 mA
|
|
供电电源 Power supply
|
12~24 VDC
|
|
|
精度等级 Accuracy level
|
0.5%FS ,0.2%FS 0.1%FS
|
默认default 0.5% FS
|
|
补偿温度Compensating temperature
|
-10~70 ℃
|
|
|
工作温度 Working temperature
|
-20~80 ℃
|
|
|
零点温度漂移Zero temperature drift
|
0.5% FS（MAX）
|
|
|
灵敏度温度漂移Sensitivity temperature drift
|
0.5% FS（MAX）
|
|
|
压力过载Pressure overload
|
10MPa以下2倍；25MPa以上1.5倍
|
Less than 2 times 10MPa; 25MPa or more than 1.5 times
|
|
机械振动Mechanical vibration
|
20G（20-5000Hz）
|
|
|
响应时间Response time
|
每秒20次
|
20 times per second
|
|
稳定性stability
|
≤0.2%FS/年（year）
|
|
|
绝缘度insulation
|
≤500㏁
|
|
|
防护等级Class of protection
|
IP65
|
|
|
外壳材料Housing material
|
外壳低铜铝合金；304不锈钢接头
|
Low copper aluminum alloy shell; 304 stainless steel joint
|
|
介质兼容Media compatible
|
与316L兼容的流质介质
|
Liquid media compatible with SS 316L
|
